Packaging Equipment

Quantitative Packaging Scale

Application

It is composed of automatic weighing, packaging and sealing, feeding and other parts. t is widely used in petrochemical, chemical fertilizerbuilding matenials, grain, ports, logislics and other industries to realize the automalion of the whole process from the finished product to theweighing and packaging and complete automalic feeding, weighing, bagging, sealing and other operating procedures in sequence.

Description

1.Measurement, sewing and conveying are automatically completed

2.Intelligent instrument, high precision and fast speed

3.Cylinders, solenoid valves and PLC use big brand products with good reliability, high precision and long service life

4.The sewing machine is of high quality, fast speed and good stability

Parameters

Name Model Rated weight Bagging speed Suitable material
kg/bag bag/h /
Gate Feeding Quantitative Packaging Scale ZZ-50Hopper-free scale 20-50 200-350 pellet
ZZL-50Single-free scale 20-50 400-700 pellet
ZZL-50SDouble-free scale 20-50 700-950 pellet
Belt Feeding Quantitative Packaging Scale BCP-50WHopper-free scale 20-50 200-300 Powder/pellet
BCP-50Single hopper scale 20-50 300-500 Powder/pellet
BCP-50SDouble hopper scale 20-50 500-700 Powder/pellet
