Screening Equipment

Cylinder Grading Screen

Application :

The cylinder grading screen is mainly used for the sifting of dry powdery or granular materials, which is widely applied to organic fertilizer, food, medicine, abrasives and many other industries.

Description

LoChamp’s cylinder grading screen is designed with a fully sealed structure to prevent material spillage. In addition, the section contacting with materials is made of stainless steel, so it is corrosion resistant and features a long service life.

Both sides of the cylinder grading screen’s box can be completely opened to facilitate users to clean the screen surface and update the screen bottom.

Application

The cylinder grading screen is mainly used for the sifting of dry powdery or granular materials, which is widely applied to organic fertilizer, food, medicine, abrasives and many other industries.

Parameters

Specification

Rotational speed (r/min)

Power(kw)

Screen angle (o)

Screen size(mm)

Capacity(t/h)

FSY1.2X4.8

19

5.5

5

1-4.5

6-10

FSY1.5X5

17

7.5

5

1-4.5

10-15
