Description
1.Make cooling full, prolong material’s storage time
Advanced theory of countercurrent cooling, widely applied in feed pellet cooler, such as Granulation, Expansion, extruder, expanded and so on.
Octagonal section ensures no death corner and is propitious to cool material.New Rotary feeder ensures full and thorough cooling of materials and can evidently reduce the breakage rate.
2.Fence stripper agencies, discharging uniformly
Reciprocating linear motion guarantees smooth and uniform discharge.Overall vertical layout, simple and beautiful.
Features
Humanization design, long service life.
Access door in the front, the side and viewing window on top cover assure easy observation and inspection.
Discharge with pressure plate improves unloading capacity, reduces distortion and extends the life of the part.
Smooth and reliable drive unit with gear motor, low noise, easy for installation and maintenance.
Parameters
|
Model |
After coolingtemperature |
Power(kw) |
Capacity (t/h) |
Size(mm) |
|
SKLN11 |
≤RT+3℃ |
0.75 |
3 |
1325×2516×1384 |
|
SKLN15 |
≤RT+3℃ |
1.5 |
7 |
1722×3196×2470 |
