The Scope of Application
This quality retainer is widely matched with various granulators for feed, fertilizer and biomass industries. It is applicable to pellet production of grain raw materials, mixed feed, organic fertilizer and granular materials. Suitable for large, medium and small-scale production lines, it works stably under continuous working conditions. It effectively keeps material quality and meets the production demands of different processing scenarios.
Characteristic
- The parts contact with material and steam are made of 304 stainless steel;
- Ensure uniform quality by spiral conveying and striking plates at discharge port;
- Adopts double-layer structure (Interlayer+thermal insulation), the interlayer is vented withsteam, so that the material temperature inside without decrease; the thermal insulation layerprevents the outer layer from radiating heat, and high thermal efficiency;
- Equipped with variable-frequency and adjustable-speed motor to ensure the materialreaches the ideal coefficient of fullness;
- With many observation holes for checking the material distribution in the cylinder at anytime;
- Equipped with a large opening door for easy cleaning of the material in the cylinder;
- Low noise, no oil leakage and durable;
Parameters
| Model | Power(kw) | Capacity (t/h) | Time of Quality Retaining(min) | Inner Cylinder Plate Thickness(mm) | Outer Cylinder Plate Thickness(mm) | Thickness of Blade(mm) |
| SBZL60x320 | 4 | 6 | ＞3 | 6 | 4 | 6 |
| SBZL80x320 | 5.5 | 12 | ＞3 | 8 | 4 | 8 |
| SBZL80x400 | 5.5 | 15 | ＞3 | 8 | 4 | 8 |
| SBZL100x400 | 7.5 | 22 | ＞3 | 8 | 4 | 8 |
| SBZL110x400 | 11 | 25 | ＞3 | 8 | 4 | 8 |
