Description
Belt feed scale is suitable for powder and granular materials, spiral feed scale applies only to powder material.
Features
1.Accuract measurement owning to unique anti-shock device, high speed for bagging, stable operation under complicated working conditions;
2. easy maintenance;
3.The key parts are all imported with long service life and strong anti-jamming ability;
4.Modify at any time and track automatically;
Parameters
|
Model |
ZZP-50 |
ZZLP-50 |
ZZX-50 |
ZZLX-50 |
ZZ-50 |
ZZL-50 |
|
Size(mm) |
2500×2700×1556 |
2500×2700×2800 |
1742×900×2594 |
2500×2700×2596 |
/ |
/ |
|
Static Precision |
Ref (0.2) × (0.2) |
|||||
|
Dynamic Precision |
10g |
|||||
|
Power/Gas |
AC 380V 50HZ 0.4-0.8 Mpa |
|||||
|
Power(kw) |
1.5 |
1.5 |
1.5+0.75 |
1.5+0.75 |
/ |
/ |
|
Bagging Speed(Bag/h) |
200-300 |
300-500 |
150-250 |
240-400 |
200-350 |
400-700 |
